Home > LED Flex > One Color >   SMD2835 8mm Single Color Led Strip 60LEDs/m DC5V/DC12V/DC24V

SMD2835 8mm Single Color Led Strip 60LEDs/m DC5V/DC12V/DC24V

Description

- Use 2835 high brightness led, high purity gold line,SANAN chip.
- 60LEDs/M, high luminance efficiency.
- Input voltage DC5V/12V/24V.
- 8mm flexible PCB, FPC color: white.
- Standard length 5m per roll. The length also can be customized.




Share to

Facebook Twitter g+

Specification

Product Parameter

    PN
  S008060BA1LZ     S008060BB1LZ
  S008060BC1LZ
    Voltage
  DC5V
     DC12V
  DC24V
    LED Type
  SMD 2835     SMD 2835
  SMD 2835
    Cutting unit
 16.66mm
     50mm
  100mm
    LED Quantity  60LEDs/m     60LEDs/m
  60LEDs/m
     Color  3000K/4000K/6500K      3000K/4000K/6500K  3000K/4000K/6500K
     Lumens
  350lm      520lm  520lm
    Dimension
  5000*8mm
     5000*8mm
  5000*8mm
    Materiar  FPC
     FPC  FPC
    Power
  4.8W/m
     4.8W/m
  4.8W/m
    IP Rate
  IP20/IP64/IP65/IP67     IP20/IP64/IP65/IP67  IP20/IP64/IP65/IP67
    O.T  -25℃ ~ 60℃
     -25℃ ~ 60℃  -25℃ ~ 60℃


Dimension (unit:mm)

IP Rate
