Description
· 12x22 arc surface luminous neon light bar, can bend left and right;
· Light source: highlights lamp beads;
· Control method: Differential parallel dmx512 (1990) signal protocol,
built -in anti -interference module,
· Strengthen anti -interference ability;
· Craft material: high -light transmission and environmental -friendly
silicone material, good flexibility of silicone material;
· Optical design: Unique optical light structure design, uniform
light on the surface, no shadow,
· The light -free spots, the light is very soft;
· Exterior design: simple and fashionable, exquisite and unique
brings better lighting performance to indoor/outside applications;
· Product certification: UL, CE, RoHS;

|
PN |
N012060CC4DC0
(N1222)Arc |
N012060CC4DE1 (N1222)Arc |
|
Voltage |
DC24V |
DC24V |
|
LED Type |
SMD5050 |
SMD5050 |
|
LED Qty |
60LEDs/m |
60LEDs/m |
|
Color |
RGBW |
RGBW |
|
Lumen |
R:60 G:138 B:40 W:197lm/m |
R:60 G:138 B:40 W:197lm/m |
|
Dimension |
5000*12*22mm |
5000*12*22mm |
|
Pixel |
10Pixel/m TM512AC |
10Pixel/m Hi512 |
|
Power |
19.2W/m |
19.2W/m |
|
Max
Length |
15m |
15m |
| O.T | -25℃ ~ 60℃ |
-25℃ ~ 60℃ |
Note: Length tolerance applies. Actual product dimensions may vary
