Description
-Use 2835 high brightness led, high purity gold line,
SANAN chip.
-130LEDs/M, high luminance efficiency and high Ra.
-Input voltage DC48V. Luminance efficiency
-Constance current design,brightness keeps the same
-Flexible PCB, FPC color: white.
-1+2 OZ copper thickness FPC, 10mm PCB width.
-Single-ended power supply for 30 meters at most
|
PN |
S010130BJ1HZ |
|
Voltage |
DC48V |
|
LED Type |
SMD 2835 |
| LED Quantity |
130LEDs/m |
|
Dimension |
5000*10mm |
| Cutting Length |
100mm/13LEDs |
| Luminance/m |
700Lm |
|
SDCM |
<5, 3 step 1 bin |
|
RA |
90 |
|
Power |
7W/m |
|
Beam Angle |
120° |
|
IP Rating |
IP20/IP64/IP65/IP67 |
| O.T | -25℃ ~ 60℃ |
Dimension (unit:mm)
